6 Ton Electric Automatic Guide Robot Battery Operated Four Wheel Vehicle

Henan Perfect Handling Equipment Co., Ltd.
Contact Now

6 Ton Electric Automatic Guide Robot Battery Operated Four Wheel Vehicle

Brand Name : Battery Rail Transfer Cart

Model Number : Battery Rail Transfer Cart

Certification : CE ISO SGS

Place of Origin : Henan China

MOQ : 1

Price : Usd5800-9000/set

Payment Terms : L/C, T/T

Supply Ability : 30sets/week

Delivery Time : 20 work days after received balance payment

Packaging Details : Trap and wooden case

Type : Battery Rail Transfer Cart

Motor Power : 1-15

Material : Carbon Steel

Product Name : 6 ton electric Automatic Guide robot battery operated four wheel vehicle for industrial material handling

Turnning Radius(mm) : 2501-5201

Wheel Base(mm) : 1500-1800

Motor Power(Kw) : 3.5-15

Contact Now

6 Ton Electric Automatic Guide Robot Battery Operated Four Wheel Vehicle

PERFECT 6 ton electric robot battery operated four wheel vehicle for industrial material handling are used to transport steel coils and pipes for metal industry. This 6 ton electric robot battery operated four wheel vehicle for industrial material handling are designed to be an extremely cost effective, safe and flexible load moving alternative.The 6 ton electric robot battery operated four wheel vehicle for industrial material handling are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. The 6 ton electric robot battery operated four wheel vehicle for industrial material handling is sometimes called a heavy transporter, headless transporter or self-propelled modular transporter.

Customized of Material Transport Trailer

PERFECT is specialized in designing and manufacturing of heavy duty Material Transfer Cart:
Transfer Cart: Trackless transfer car, Battery operated transport trolley, Coils cart, Ladle transfer cart, Hydraulic scissors lift table cart etc.
Rail Cart: Rail transfer cart, Cross-rail transport trolley, Curved rails transfer cart, S shape railway transport cart, L shape track transporter etc.
Industrial Trailer: Flatbed trailer, Factory trailer, Utility trailer, Workshop transfer trailer, Airport baggage cargo trailer, Car transport trailer, Motorized transfer trailer etc.
Cargo Transportation: Die cart, Coils transport cart, pipes transfer carriage, steel beam transporter, aluminum plate transport vehicle, transformer carrier bogie
Special Handling Equipment: Ladle transfer trolley, Ferry Transfer wagon, Cross-rail transport equipment, Motorized turntable, Vacuum furnace transfer cart, Automatic vehicle etc.

Main Componences

6 Ton Electric Automatic Guide Robot Battery Operated Four Wheel Vehicle

Technical Table

Rated Load(T) 5 10 15 20 30 40 50
Ground Clearance(mm) 50 50 50 50 50 50 50
Wheel Base(mm) 1500 1500 1500 1700 1700 1800 1800
Turnning Radius(mm) 2501 3101 3401 3901 4301 4801 5201
Axles Distance(mm) 2500 3100 3400 3900 4300 4800 5200
Motor Power(Kw) 3.5 5 6 7 10 12 15
Running Speed(m/min) 0-15 0-15 0-15 0-15 0-15 0-12 0-12
Cart Weight(t) 4.3 5.3 6.6 7.9 8.8 10 10.5
Impacted Rated Load(t) 7.5 15 22.5 30 45 60 75
Battery Capacity(Ah) 180 160 180 180 250 300 330
Battery Voltage(v) 36 48 48 48 48 48 48
Wheel Quantity 4 4 4 4 44 4 4
Ground Requirement Cement Floor Cement Floor Cement Floor Cement Floor Cement Floor Cement Floor Cement Floor

Application

6 Ton Electric Automatic Guide Robot Battery Operated Four Wheel Vehicle
