heavy load 15T automated plate transfer cart trackless machine

Product Categories
Henan Perfect Handling Equipment Co., Ltd.
Contact Now

heavy load 15T automated plate transfer cart trackless machine

Brand Name : 15T automated plate transfer cart trackless machine

Model Number : 15T automated plate transfer cart trackless machine

Certification : CE ISO SGS

Place of Origin : China(mainland)

MOQ : 1 set

Price : USD 2000~7600 SET

Supply Ability : 100 SETS MONTH

Packaging Details : trap and wooden case

Load Capacity : 1-300T

Table Size : Customized

Height : Customized

Running Speed : 0-50/min(Adjustable)

after-sales Service Provided : Engineers available to service machinery

Product Name : 15T automated plate transfer cart trackless machine

Contact Now

15T automated transfer cart trackless machine

Product Description

Henan Perfect Handling Equipment Co., Ltd is a collection of research and development, design, manufacturing as one of professional international manufacturing company of 15T automated plate transfer cart trackless machine. Our company has been founded for 13 years and has become enterprise in the 15T automated plate transfer cart trackless machine business.

The BWP series 15T automated plate transfer cart trackless machine is consisted of power source, gear train, steel structure bearing frame, steering gear, running gear, control system and fault diagnosis module. other functions. It can turn around on the cement floor.All the 15T automated plate transfer cart trackless machine are equipped with warning alarm and security detection apparatus, and the alarm would ring and the car would stop immediately if there was any obstacle or pedestrian in the running path of the 15T automated plate transfer cart trackless machine. Also, we will provide intelligent automatic rapid charger with the 15T automated plate transfer cart trackless machine. Positioning fixture, lift platform and other assistive device are optional to meet different demands on various occasions. The PLC is also alternative if it’s necessary.

heavy load 15T automated plate transfer cart trackless machine

heavy load 15T automated plate transfer cart trackless machine

Technical Parameters
Model BWP-5t BWP-20t BWP-30t BWP-40t BWP-50t
Rated Load(t) 5 20 30 40 50
Impacted rated load(t) 7.5 30 45 60 75
Structure of Frame Steel plates welded, beam
thickness of the steel plate 8 14 14 16 16
Cart weight(t) 4.3 7.9 8.8 10 10.5
Max. wheel load (t) 2.8 5.6 7.7 10 12
Ground requirement Cement floor or Steel plate ground
Ground Clearance(mm) 50 50 50 50 50
Table size (mm) 3000 X 2000 4500 X 2200 5000 X 2200 5500 X 2300 6000 X 2300
Height of the whole cart (mm) 450 600 650 700 700
Wheel base (mm) 1500 1700 1700 1800 1800
Axles distance (mm) 2500 3900 4300 4800 5200
Turning radius (mm) 2501 3901 4301 4801 5201
Turning type Turning while driving with no stop
Control method for turning Control button
Turning structure Mechanical
Motor power (KW) 3.5 7 10 12 15
Wheel diameter (mm) 300 (4) 400 (4) 400 (6) 500 (6) 500 (6)
Wheel material ZG55+hydropurture
Running speed (m/min) 0-15 0-12
Brake principle Electric magnetic brake
Ground balance Mechanical automatic adjustment
Operation method With wire or no wire
Battery model D-250 24pieces D-440 24pieces D-250 36pieces D-330 36pieces D-440 36pieces
Battery maintainance Free of maintainance
Charger's installation Installed on cart Split-type
Cart color Yellow and warning sign
Charger's function Automatic stop for obstacles
Radar control 3-0.3 m, Automatic stop for obstacles
Warning equipment Sound and light
Other functions Turning light, night light and power display

Detailed Image Of 15T automated plate transfer cart trackless machine​

heavy load 15T automated plate transfer cart trackless machine

Functions & Advantages Of 15T automated plate transfer cart
  • The 15T automated plate transfer cart trackless machine is Anti-high temperature,Anti-high explosion;
  • The 15T automated plate transfer cart trackless machine is powered by battery;
  • With lifting holes,The Trackless Machine is convenient to shipment;
  • The 15T automated plate transfer cart trackless machine has a feature of stable start, big starting power, long lifetime;
  • The 15T automated plate transfer cart trackless machine can spin around 360 degrees;
  • Running distance of 15T automated plate transfer cart trackless machine is unlimited;
  • Safe and convenient operation is available for 15T automated plate transfer cart trackless machine;
  • High using frequency for 15T automated plate transfer cart trackless machine.
