30T Based Trolley Material Concrete Floor Transfer Die Cart

Brand Name : Perfte

Model Number : Material Transfer Cart

Certification : CE ISO SGS

Place of Origin : Henan China

MOQ : 1

Price : Usd 6800-7000/set

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 60 sets/week

Delivery Time : 45 work days after received balance payment

Packaging Details : Trap and wooden case

Product Name : Rail Based Trolley Material Transfer Cart for Heavy Industrial Materials Handling

Original : Henan China

Wheel Diameter(mm) : 350-550

Ground Clearance(mm) : 50-80

Wheel Quantity : 4

Running Speed(m/min) : 0-25

Type : Material handling equipment

Contact Now

30T Based Trolley Material Concrete Floor Transportation Die Cart

Introductions

PERFECT's heavy duty material transport cart are movable platforms used for the horizontal movement of materials, assemblies and other items. It is powered by storage battery, which is installed on the transfer carts. The transfer trolleys are manual guide vehicles equipped with specialized drive systems which make it possible to easily, precisely and safely move up to 200 tons. Usually the heavy duty material transport cart are used to accommodate the needs of a wide range of industries including Steel, Aluminum, Automotive, Heavy Manufacturing and others.These heavy duty material transport cart are designed to operate on floor mounted rails and are used to transport heavy materials across crane bays or in areas not serviced by an overhead crane.

30T Based Trolley Material Concrete Floor Transfer Die Cart

Product Parameters

Model
 BDG-2T BDG-10T BDG-20T BDG-30T BDG-50T BDG-63T BDG-150T
Rated load (T) 2 10 20 30 50 63 150
Table size(mm) length(L) 2000 3600 4000 4500 5500 5600 10000
Width(W) 1500 2000 2200 2200 2500 2500 3000
Height(H) 500 550 600 650 700 800 1200
Wheel Diameter(mm) Φ270 Φ300 Φ350 Φ400 Φ500 Φ600 Φ600
Wheel Quantity 4 4 4 4 4 4 8
Running speed (min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 0.8 1.5 2.5 4 5.5 7.5 15
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 221.4 265.2
Recommended Rail Model P15 P18 P24 P38 P43 P50 QU100

Advantages

  • Simple structure, easy in installation and maintenance.
  • The transfer vehicle mounted on rails can run on the C-form track or S-form track.
  • safety, flexibility, high using frequency, long using time, long service life.
  • Custom deck configurations may include lift, tilt, or rotate function.
  • Available safety equipment includes horn, lights, emergency stop, bumpers and detector.

opreating principle

This transfer cart get the power from the battery. The current is supplied to pulling motor through electric control system, which makes the car start, stop, move forward, turn around, change speed, etc. The transfer cart can run on curved rails and can use as ferry car. The battery powered transfer cart is suitable for all kinds of transport occasion since its travel distance is unlimited and low requirement to the track.
